Sunpal All-in-One Residential 15kW 20kW 25kW Hybrid Solar System

Download Inquiry

Specification

Model	SP-15KW200KWh	SP-20KW200KWh	SP-25KW200KWh
Battery Type	Lithium-ion
Configuration	14 modules + 1 BPU
Rated capacity/voltage/energy	280Ah/716.8V/200.7kWh
Voltage range	627.2-795.2V
Rated charge/discharge	0.5C
AC Input/Output Data
Rated AC Input/Output Active Power (W)	15000	20000	25000
Rated AC Input/Output Current (A)	22.8/21.8	30.4/29	37.9/36.3
Max. AC Input/Output Current (A)	25/24	33.4/31.9	41.7/39.9
Max. Three-phase Unbalanced Output Current (A)	30	35	41.7
Max. Continuous AC Passthrough Current (A)	80
Peak Power (Off Grid)	1.5 times of rated power, 10s
Power Factor Adjustment Range	0.8 leading to 0.8 lagging
Output Frequency and Voltage	50/60Hz; 3L/N/PE, 230/400Vac, 127V/220V, 277V/480V
Grid Type	Three Phase
Total Harmonics Current Distortion (THDi)	<3% (of nominal power)
DC Current Injection	<0.5% In
Battery Input Data
Max. Charging Current (A)	50
Max. Discharging Current (A)	50
Number of Battery Input	1
Charging Strategy for Li-Ion Battery	Self-adaption to BMS

Q : 1. What is a hybrid solar system? A : A hybrid system combines solar panels, batteries, and a hybrid inverter. It stores energy for later use and works with or without grid power.
Q : 2. How does a hybrid system operate during outages? A : When the grid goes down, the system automatically powers essential loads using stored solar energy to keep your home running smoothly.
Q : 3. Can this system power a large home or small business? A : Yes. With up to 25kW output and 200kWh of storage, it easily supports high-consumption applications.
Q : 4. What makes this system “all-in-one”? A : It includes panels, hybrid inverter, BMS-integrated lithium batteries, and smart controls—ready for installation and operation.
Q : 5. What type of electrical output does it support? A : It provides three-phase AC output (230/400V, 127/220V, or 277/480V), compatible with international grid standards.
