HomeSolar InverterDeye60-80kw Deye Hybrid High-Efficiency Inverter for Solar+Storage Systems

60-80kw Deye Hybrid High-Efficiency Inverter for Solar+Storage Systems

  • 80kW Hybrid Three-Phase Inverter for Factory Use – Featuring Industrial-Grade Peak Shaving, Grid Backup Mode, and Solar/Battery Integration to Reduce Energy Costs
  • 60kW Hybrid Solar Inverter (50Hz/60Hz Dual Frequency) - IP65 Rated for Farm PV+Storage Systems with Dual MPPT & Generator Integration Manufacturer
  • 80kW Hybrid Inverter with Smart Peak Shaving Technology for Load Optimization, Enhanced Grid Independence with Backup Power Functionality for Maximum Efficiency and Cost Savings Supplier
  • 60kW 70KW Hybrid Inverter for Farm Irrigation, Cold Storage & Livestock Operations - Supports 50Hz/60Hz Grids & Off-Grid Mode Manufacturer
  • 80kW Hybrid Three-Phase Inverter for Factory Use – Featuring Industrial-Grade Peak Shaving, Grid Backup Mode, and Solar/Battery Integration to Reduce Energy Costs
  • 60kW Hybrid Solar Inverter (50Hz/60Hz Dual Frequency) - IP65 Rated for Farm PV+Storage Systems with Dual MPPT & Generator Integration Manufacturer
  • 80kW Hybrid Inverter with Smart Peak Shaving Technology for Load Optimization, Enhanced Grid Independence with Backup Power Functionality for Maximum Efficiency and Cost Savings Supplier
  • 60kW 70KW Hybrid Inverter for Farm Irrigation, Cold Storage & Livestock Operations - Supports 50Hz/60Hz Grids & Off-Grid Mode Manufacturer

60-80kw Deye Hybrid High-Efficiency Inverter for Solar+Storage Systems

    Intelligent generator control: supports automatic start and stop of diesel generators, and can set SOC trigger conditions as a backup power source.
    Industrial grade protection (IP65): waterproof and dustproof, suitable for outdoor installation, adapt to harsh environment (-40°C to 60°C)
    Multiple working modes: support grid-connected, off-grid, UPS seamless switching, optional
    Time of Use (TOU) function: customize battery charging and discharging time periods, use off-peak electricity prices to charge and peak electricity prices to reduce electricity costs.
    Dual battery interface: supports two battery groups in parallel to increase energy storage capacity, optional voltage mode (160-1000V) or SOC mode management
    Multiple protection mechanisms: including island protection, DC insulation monitoring, anti-reverse current (CT/meter monitoring), over-temperature/overload/short-circuit protection, etc.

Share:

Download Inquiry
ModelSUN-60K-SG02HP3-EU-EM4SUN-75K-SG02HP3-EU-EM6SUN-80K-SG02HP3-EU-EM6
Battery Input Data
Battery TypeLi-lon
Battery Voltage Range (V)160~1000
Max. Charging Current (A)80+80
Max. Discharging Current (A)80+80
Number of battery input2
Charging Strategy for Li-Ion BatterySelf-adaption to BMS
PV String Input Data
Max. DC Input Power (W)96000120000128000
Max. DC Input Voltage (V)1000
Start-up Voltage (V)180
MPPT Range (V)150-850
Rated DC Input Voltage (V)650
Max. Operating PV Input Current (A)36+36+36+3636+36+36+36+36+36
Max. Input Short-Circuit Current (A)54+54+54+5454+54+54+54+54+54
No. of MPP Trackers/
No. of Strings MPP Tracker		4/2+2+2+26/2+2+2+2+2+2

Q :

How can I monitor the inverter’s performance remotely

A :

Use the built-in Wi-Fi interface or optional data logger (GPRS/4G/LAN). Download the Deye monitoring app to view real-time data (PV generation, load consumption, battery SOC).

Q :

How does the inverter prevent excess energy from being exported to the grid?

A :

The inverter powers both backup and home loads without exporting excess energy to the grid. External CTs or a smart meter must be installed to detect grid feedback.

Q :

What safety precautions should I take during installation?

A :

Always disconnect AC and DC circuits separately and wait 5 minutes before maintenance. Ensure proper grounding to prevent electric shock. Use approved DC cables for PV and battery connections. Avoid direct sunlight, rain, or high humidity during installation.

Q :

What is the maximum charging and discharging current?

A :

The inverter supports a maximum charging current of 80A + 80A and a maximum discharging current of 80A + 80A, depending on the model and battery configuration.

Q :

What protection functions are included?

A :

The inverter incorporates multiple protection mechanisms, including anti-islanding protection, DC insulation monitoring, reverse-current protection, over-temperature protection, overload protection, and short-circuit protection.
