    Trina 710W 715W 720W Bifacial Dual Glass N-Type i-TOPCon Solar Module

    • Good Price for Trina 695W 700W 705W 710W 715W 720W 132 Cells Bifacial Dual Glass N-Type i-TOPCon Solar Module Manufacturer
    • Best prices for Trina bifacial dual glass 132-cell N-Type iTOPCon solar panels ranging from 695W to 720W Manufacturer
    • Solar 132-cell N-Type iTOPCon bifacial dual glass panels from 695W up to 720W at best prices Manufacturer
    • Competitive pricing for Trina 695W to 720W N-Type iTOPCon bifacial dual glass solar modules with 132 cells Manufacturer
    • Good Price for Trina 695W 700W 705W 710W 715W 720W 132 Cells Bifacial Dual Glass N-Type i-TOPCon Solar Module Manufacturer
    • Best prices for Trina bifacial dual glass 132-cell N-Type iTOPCon solar panels ranging from 695W to 720W Manufacturer
    • Solar 132-cell N-Type iTOPCon bifacial dual glass panels from 695W up to 720W at best prices Manufacturer
    • Competitive pricing for Trina 695W to 720W N-Type iTOPCon bifacial dual glass solar modules with 132 cells Manufacturer

    Trina 710W 715W 720W Bifacial Dual Glass N-Type i-TOPCon Solar Module

      Maximum power output up to 720W
      Positive power tolerance 0~+5W
      Module efficiency up to 23.2%
      Low-voltage design increases string capacity
      80% bifaciality for up to 30% rear gain
      Reliable 30-year power output warranty

    Share:

    Download Inquiry
    Solar CellsN-type i-TOPCon Monocrystalline
    No. of cells132 cells
    Module Dimensions2384×1303×33 mm (93.86×51.30×1.30 inches)
    Weight38.3 kg (84.4 lb)
    Front Glass2.0 mm (0.08 inches), High Transmission, AR Coated Heat Strengthened Glass
    Encapsulant materialPOE/EVA
    Back Glass2.0 mm (0.08 inches), Heat Strengthened Glass (White Grid Glass)
    Testing ConditionSTC      NOCTSTC       NOCTSTC      NOCT        STC      NOCTSTC      NOCTSTC       NOCT
    Peak Power Watts-PMAX (Wp)*695       531700        534705       540        710       543715        547720        551
    Maximum Power Voltage-VMPP (V)40.3      37.940.5       38.040.7      38.3        40.9      38.541.1       38.741.3       38.8
    Maximum Power Current-IMPP (A)17.25    14.0017.29    14.0417.33    14.08        17.36    14.1217.40   14.1417.44    14.19
    Open Circuit Voltage-VOC (V)48.3      45.948.6      46.148.8     46.3        49.0     46.549.2      46.749.4      46.9
    Short Circuit Current-ISC (A)18.28    14.7218.32    14.7618.36    14.80      18.40   14.8318.44   14.8618.49    14.90
    Module Efficiency η m (%)22.4 22.5 22.7       22.9 23.0 23.2
    Backside Power Gain5%10%5%10%5%10%5%   10%5%10%5%10%
    Total Equivalent power -PMAX (Wp)730 765 735 770 740 776 746    781 751 787 756 792
    Maximum Power Voltage-VMPP  (V)40.3 40.3 40.5 40.5 40.7 40.7 40.9    40.9 41.1 41.1 41.3 41.3
    Maximum Power Current-IMPP (A)18.11 18.98 18.15 19.02 18.20 19.06 18.23    19.10 18.27 19.14 18.31 19.18
    Open Circuit Voltage-VOC  (V)48.3 48.3 48.6 48.6 48.8 48.8 49.0    49.0 49.2 49.2 49.4 49.4
    Short Circuit Current-ISC (A)19.19 20.11 19.24 20.15 19.28 20.20 19.32    20.24 19.36 20.28 19.41 20.34

    Q :

    1. What makes this Trina 720W panel ideal for utility-scale systems?

    A :

    It delivers high power density with lower voltage, boosting energy yield while reducing BOS and LCOE.

    Q :

    2. How does i-TOPCon tech enhance module efficiency?

    A :

    It improves rear reflectivity and contact resistance, achieving 23.2% efficiency on the 210mm platform.

    Q :

    3. Can this module perform well in challenging environments?

    A :

    Yes, it resists PID, ammonia, salt mist, and extreme temperatures with dual-glass protection and ISO/IEC certifications.

    Q :

    4. What kind of rear-side gain does the bifacial design offer?

    A :

    Up to 10%–30% energy gain from the rear side depending on albedo, thanks to 80±5% bifaciality.

    Q :

    5. What warranty terms apply to this product?

    A :

    Backed by a 12-year workmanship warranty and a 30-year linear power output warranty with 0.4% annual loss.
