    Sunpal 5kWh Wall-Mounted Lithium Battery for Home Solar

    • 5kWh Wall-Mounted LiFePO₄ Battery for Home Solar – Manufacturer
    • Wall-Mounted 5kWh Lithium Battery for Residential Energy – Supplier
    • 5kWh LiFePO₄ Solar Battery for Home Use – Wholesaler
    • Wall-Mounted Lithium Battery for Solar Storage – Dealer
    • 5kWh Wall-Mounted LiFePO₄ Battery for Home Solar – Manufacturer
    • Wall-Mounted 5kWh Lithium Battery for Residential Energy – Supplier
    • 5kWh LiFePO₄ Solar Battery for Home Use – Wholesaler
    • Wall-Mounted Lithium Battery for Solar Storage – Dealer

    Sunpal 5kWh Wall-Mounted Lithium Battery for Home Solar

      5.12kWh capacity, compact home backup
      100A output, 6000+ cycle lifespan
      Wall-mounted with plug-in design
      Supports CAN/RS485/RS232
      Only 49kg, size 440×500×142 mm
      Compatible with hybrid/off-grid inverters

    Share:

    Download Inquiry
    Product Sepecifications
    ModelPP-Y4-5kWhPP-Y4-10kWhPP-Y4-15kWh
    Rated Voltage51.2V
    Rated Capacity(C5)100Ah200Ah300Ah
    Battery Cell3.2V 100Ah Prismatic Battery Cell
    Configuration16S1P16S2P16S3P
    Parallel CapacityYes,15units maximum
    Max.Charge Cuurent50A100A100A
    Continuous Discharge Cuurent100A200A200A
    Discharge Cut-of Protect Voltage45.6V
    Charge Cut-of Protect Voltage56.16V
    Cycle Life6000 cycles@90%DOD,0.2C,SOH80%
    Communication PortCan,RS485,RS232
    L*W*H(mm)440*500*142442*820*142660*820*140
    Weight(kg)49kg98kg165kg
    Protection RatingIP21(Indoor)
    InstallationWall mounted
    Discharge Temperature(℃)-20~60
    Charge Temperature(℃)0~55
    Lithium Battery StandardUL1642/IEC62619/UN38.3/ROHS/CE-EMC

    Q :

    1. What can this 5kWh battery power in a home setup?

    A :

    It supports daily energy backup for lights, routers, fans, and small appliances in solar or grid-tied systems.

    Q :

    2. Is it expandable if I need more capacity later?

    A :

    Yes, up to 15 units can be connected in parallel, scaling up to 75kWh total storage.

    Q :

    3. Can I monitor the battery's performance?

    A :

    Yes, the LED display shows SOC and battery status, and supports inverter-level communication via CAN/RS485.

    Q :

    4. How long does the battery last in real-world use?

    A :

    It provides over 6000 cycles at 90% DOD—around 15 years of typical daily usage.

    Q :

    5. Is it suitable for wall-mounted indoor installations?

    A :

    Yes, it's designed for wall mounting and has IP21 indoor protection with natural air cooling.

    Q :

    6. What safety certifications does it meet?

    A :

    Certified to UL1642, IEC62619, UN38.3, ROHS, and CE-EMC standards.
