Electrical Parameters (STC*) | ||||||||||||||||
Module Type: SP440M-54H | 410 | 415 | 420 | 425 | 430 | 435 | 440 | |||||||||
Maximum power (Pmax/W) | 410 | 415 | 420 | 425 | 430 | 435 | 440 | |||||||||
Open Circuit Voltage (Voc/V) | 38.10 | 38.25 | 38.49 | 38.73 | 38.96 | 39.20 | 39.44 | |||||||||
Short Circuit Current (Isc/A) | 13.85 | 13.92 | 13.99 | 14.06 | 14.13 | 14.20 | 14.27 | |||||||||
Voltage at Maximum power (Vmpp/V) | 31.20 | 31.42 | 31.63 | 31.84 | 32.04 | 32.25 | 32.45 | |||||||||
Current at Maximum Power (Imp/A) | 13.14 | 13.21 | 13.28 | 13.35 | 13.42 | 13.49 | 13.56 | |||||||||
Module Efficiency(%) | 21.00 | 21.25 | 21.51 | 21.76 | 22.02 | 22.28 | 22.53 |
Temperature Characteristics | |||||
Nominal Operating Temperature (NMOT) | 45±2°C | ||||
Temperature coefficient of pmax | -0.29%°C | ||||
Temperature coefficient of voc | -0.25%°C | ||||
Temperature coefficient of ISC | +0.045%°C |
