High-Efficiency TOPCON 720W 750W Solar Panels for Commercial Applications

  • High Efficiency Topcon 750W Solar Panel for Commercial Use
  • Bifacial Topcon 750W PV Module with N-Type Technology
  • Advanced Topcon 750W Solar Module for Utility-Scale Systems
  • Topcon 750W Solar Panel – Low Degradation, High Output Performance
  • High Efficiency Topcon 750W Solar Panel for Commercial Use
  • Bifacial Topcon 750W PV Module with N-Type Technology
  • Advanced Topcon 750W Solar Module for Utility-Scale Systems
  • Topcon 750W Solar Panel – Low Degradation, High Output Performance

High-Efficiency TOPCON 720W 750W Solar Panels for Commercial Applications

    Cell Type: 132 cells (66×2), 210×105mm
    Module Dimensions: 2384 × 1303 × 33 mm
    Weight: 37.8 kg
    Maximum Power (Pmax): 720W ~ 750W
    Operating Temperature: -40°C ~ +85°C
    Power Output Warranty: 30 Years Linear Performance Guarantee

Share:

Download Inquiry

*Specification

External Dimensions2384x1303x33mm
Weight37.8kg
Solar CellsMono crystalline 210mm (2x66pcs)
Front GlassAR Coated 2+2 mm tempered glass
FrameAnodized aluminum alloy
Junction BoxIP68
Output Cables4.0mm2 ,1200mm(+),1200mm(-), length can be customized
ConnectorMC4 Compatible
Mechanical LoadFront Side Max. 5400Pa, Rear Side Max.2400Pa
Module TypeSP720M-66HSP725M-66HSP730M-66HSP735M-66HSP740M-66HSP745M-66HSP750M-66H
Test ConditionsSTC / NOCTSTC / NOCTSTC / NOCTSTC / NOCTSTC / NOCTSTC / NOCTSTC / NOCT
Maximum Power – Pmax (W)720 / 545725 / 549730 / 553735 / 557740 / 561745 / 565750 / 569
Open Circuit Voltage – Voc (V)48.70 / 46.1048.90 / 46.3049.10 / 46.5049.30 / 46.7049.50 / 46.9049.70 / 47.1049.90 / 47.30
Short Circuit Current – Isc (A)18.69 / 15.0718.74 / 15.1118.79 / 15.1518.84 / 15.1818.89 / 15.2218.94 / 15.2618.99 / 15.30
Voltage at Pmax – Vmp (V)40.80 / 38.6041.00 / 38.2041.20 / 39.0041.40 / 39.2041.60 / 39.4041.80 / 39.6042.00 / 39.80
Current at Pmax – Imp (A)17.65 / 14.1217.69 / 14.1517.72 / 14.1817.75 / 14.2117.89 / 14.2417.82 / 14.2717.86 / 14.30
Module Efficiency – ηm (%)23.2 / —23.3 / —23.5 / —23.6 / —23.8 / —23.9 / —24.1 / —
Power Tolerance (W)(0, +4.99W)(0, +4.99W)(0, +4.99W)(0, +4.99W)(0, +4.99W)(0, +4.99W)(0, +4.99W)
Maximum System Voltage1500Vdc (IEC/UL)1500Vdc (IEC/UL)1500Vdc (IEC/UL)1500Vdc (IEC/UL)1500Vdc (IEC/UL)1500Vdc (IEC/UL)1500Vdc (IEC/UL)
Maximum Series Fuse Rating (A)35A35A35A35A35A35A35A

Q :

1. What is the advantage of a bifacial double-glass module?

A :

Bifacial double-glass modules generate power from both the front and back sides, increasing total energy output by up to 30% depending on ground reflectivity. The glass-glass structure improves durability, weather resistance, and lifespan compared to traditional backsheet modules.

Q :

2. Is this module compatible with high-voltage systems?

A :

Yes, the module supports a maximum system voltage of 1500V, making it suitable for large-scale commercial and utility projects, allowing longer strings and reducing balance of system (BOS) costs.

Q :

3. What is the warranty policy for this solar module?

A :

Sunpal offers a 15-year product warranty and a 30-year linear power output warranty, guaranteeing high reliability and long-term performance under various environmental conditions.

Q :

4. How is the module shipped and packaged?

A :

Each module is packaged with reinforced protection using wooden pallets and corner guards. A 40HQ container typically holds 594 pieces (33 pcs/pallet × 18 pallets), ensuring safe transportation and optimized loading.

Q :

5. What certifications and standards does this module meet?

A :

This module complies with international standards including IEC 61215, IEC 61730, and IEC 62941, and is manufactured under certified quality systems: ISO 9001, ISO 14001, and ISO 45001, ensuring product quality, safety, and environmental compliance.
